Mornsun LM35-10D0512-10 – 5V 4A & 12V 1A 32W SMPS AC to DC Switching Dual Output Power Supply
Mornsun LM35-10D0512-10 – 5V 4A & 12V 1A 32W SMPS AC to DC Switching Dual Output Power Supply
Couldn't load pickup availability
- Warranty- 1 Years
- Manufacturer Product No: LM35-10D0512-10
- Manufacturer: Mornsun
- Input Voltage Range: 100V ~ 277VAC
- Output Voltage: 5V & 12V
- Output Current: 4A & 1A
LM35-10D0512-10 is one of power converter design features dual output versions, which can independently supply 2 different loads in the system. The products can be used in harsh working environments with an ambient temperature range from -30°C to +70°C, without the need of a fan for further heat dissipation. In addition, the converters EMC immunity performance meets the requirements of IEC61000 standard and meet emission standard CISPR32/EN55032, class B without any external components, thus providing excellent EMC protection. The products also meet IEC/EN/UL62368/EN60335/GB4943 safety standards. The converters integrate a variety of protection features and offer a high-performance to low-cost ratio providing the best power solution for a variety of industries such as industrial control equipment, instrumentation and smart home and building equipment application.
Features:
- 85 – 305VAC or 100 – 430VDC input voltage
- Accepts AC or DC input (dual-use of sameterminal)
- Operating ambient temperature range: -30℃to+70℃
- Up to 88% efficiency
- No-load power consumption < 0.5W
- High I/O isolation test voltage up to 4000VAC
- Output short circuit, over-current, over-voltageprotection
- Over-voltage class Ⅲ(designed to meet EN61558)
- Operating altitude up to 5000m
Features/Specs:
- Manufacturer Product No: LM35-10D0512-10
- Manufacturer: Mornsun America, LLC
- Series: LM35-10D0512-10
- Type: Linear Regulator Replacement
- Number of Outputs: 2
- Input Voltage Range: 10VAC ~ 277VAC
- Output Voltage: 5V & 12V
- Output Current: 4A & 1A
- Power (Watts): 32 W
- Operating Temperature: -30°C ~ 70°C
- Efficiency: 88%
Size / Dimension
- Length: 100 mm
- Width: 97 mm
- Height: 30 mm
Applications:
- Digital Circuit
- Automation
- Power Supply
Datasheet: LM35-10D0512-10
Package Includes:
- 1 x Mornsun LM35-10D0512-10 – 5V 4A & 12V 1A 32W SMPS AC to DC Switching Dual Output Power Supply
Note: Product Images are shown for illustrative purposes only and may differ from the actual product.
