2 Channel Motor TB6612FNG and 16 Channel (PCA9685) PWM Servo Shield for Arduino
2 Channel Motor TB6612FNG and 16 Channel (PCA9685) PWM Servo Shield for Arduino
Regular price
Rs. 799.00
Regular price
Sale price
Rs. 799.00
Taxes included.
Flat Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
2 connections for 5V servos connected to the high-resolution dedicated timer - no jitter!
4 H-Bridges: TB6612 chipset provides 1.2A per bridge (3A peak) with thermal shutdown protection, internal kickback protection diodes. Can run motors on 4.5VDC to 13.5VDC.
Up to 4 bi-directional DC motors with individual 8-bit speed selection (so, about 0.5% resolution)
Up to 2 stepper motors (unipolar or bipolar) with single coil, double coil, interleaved or micro-stepping.
Motors automatically disabled on power-up.
Big terminal block connectors to easily hook up wires (18-26AWG) and power.
Reset button brought up top.
Polarity protected 2-pin terminal block and jumper to connect external power, for separate logic/motor supplies.
Specifications:
Size: 68mm * 52mm * 20mm(L*W*H).
Color: Blue.
Net Weight: 25g.
4 H-Bridges: TB6612 chipset provides 1.2A per bridge (3A peak) with thermal shutdown protection, internal kickback protection diodes. Can run motors on 4.5VDC to 13.5VDC.
Up to 4 bi-directional DC motors with individual 8-bit speed selection (so, about 0.5% resolution)
Up to 2 stepper motors (unipolar or bipolar) with single coil, double coil, interleaved or micro-stepping.
Motors automatically disabled on power-up.
Big terminal block connectors to easily hook up wires (18-26AWG) and power.
Reset button brought up top.
Polarity protected 2-pin terminal block and jumper to connect external power, for separate logic/motor supplies.
Specifications:
Size: 68mm * 52mm * 20mm(L*W*H).
Color: Blue.
Net Weight: 25g.
