Features:

1. For 1/10 scale RC vehicles, we offer Touring Cars, Buggies, Short Course Trucks, Monsters, Truggies, Rock Crawlers, and Tanks.
2. Water-proof and dust-proof, suitable for all-weather condition races.
3. Small size with built-in capacitor module.
4. Fwd/Rev/Br running mode fits for various vehicles (Fwd =Forward, Br=Brake, Rev=Reverse).
5. Great current endurance capability.
6. High-quality built-in BEC with 5V @ 3A output capacity
7. Automatic throttle range calibration, easy to use.
8. Easy to set the ESC parameters with jumpers.
9. Multiple protections: Low voltage cut-off protection for battery / Over-heat protection / Throttle signal loss protection.

Specification:

1. Fwd. Cont. / Peak Current: 60A /360A
2. Rev. Cont. / Peak Current: 30A /180A
3. Cars Applicable: 1/10: Touring Car, Buggy, Short Course Truck, Monster, Truggy, Rock Crawler and Tank
4. Motor Limit: *WP-860-DUAL-BRUSHED has two outputs to drive 2 motors. When driving 2 motors simultaneously, the Turns of the motors need to be increased.
5. 2S Lipo or 6 NiMH
   1. 540 or 550 Size Motor: ≥12T Or RPM<30000 @7.2V
6. 3S Lipo or 9 NiMH
   1. 540 or 550 Size Motor: ≥18T Or RPM< 20000 @7.2V
7. 4S Lipo or 12 NiMH
   1. Not Available
8. Cooling Fan: Without cooling fan
9. Running Modes: Forward/Reverse/Brake, Forward/Brake, Forward/Reverse
