Suitable for a broad range of voltage regulation applications
Pin Count : 3
Minimum Operating Temperature : 0 °C
Maximum Operating Temperature : +150 °C

Specifications :

• Output Voltage : -15 V
• Maximum Output Current : 1.5A
• Output Type : Fixed
• Mounting Type : Through Hole
• Maximum Input Voltage : -35 V
• Pin Count : 3
• Minimum Operating Temperature : 0 °C
• Maximum Operating Temperature : +150 °C
• Number of Outputs : 1
• Polarity : Negative
• Line Regulation : 300 mV
• Quiescent Current : 3mA
• Width : 4.6mm
• Height : 9.15mm
• Series : L79xx
• Typical Dropout Voltage @ Current : 1.1 V @ 1 A
• Length : 10.4mm Dimensions : 10.4 x 4.6 x 9.15mm
• Load Regulation : 300 mV
