OWON OW16A Handheld Digital Multimeter
OWON OW16A Handheld Digital Multimeter
Regular price
Rs. 2,249.00
Regular price
Sale price
Rs. 2,249.00
Taxes included.
Flat Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
🎟️ Available Coupons — Copy & Apply at Checkout
100% Secure Payments
Verified & Protected
Accepted Payments
UPI
Mastercard
VISA
SSL Encrypted
256-bit Encryption
- 3 5/6 bit resolution
- Multimeter + Temperature Meter
- True RMS
- NCV (non-contact voltage) sensing supported
| Measurement Range | Resolution | Accruacy | ||
| DC Voltage | 6.000V / 600.0V / 60.00V | 0.01mV | ±(0.5%+2-dig) | |
| 1000V | 1V | ±(0.8%+2-dig) | ||
| AC Voltage | 6.000V / 60.00V / 600.0V | 0.1mV | ±(0.8%+3-dig) | |
| 750V | 1V | ±(1%+3-dig) | ||
| μA | 60.00uA / 600.0μA | 0.01μA | ||
| DC Current | mA | 60.00mA / 600.0mA | 0.01mA | ±(0.8%+2-dig) |
| A | 10.00A | 0.01A | ±(1.2%+3-dig) | |
| μA | 60.00uA / 600.0μA | 0.01μA | ||
| AC Current | mA | 60.00mA / 600.0mA | 0.01mA | ±(1%+3-dig) |
| A | 10.00A | 0.01A | ±(1.5%+3-dig) | |
| Resistance | 600.0Ω / 6.000kΩ / 60.00kΩ / 600.0kΩ / 6.000MΩ | 0.1Ω | ±(0.8%+2-dig) | |
| 60.00MΩ | 0.01MΩ | ±(2%+3-dig | ||
| Capacitance | 60.00nF / 600.0nF / 6.000μF / 60.00μF | 0.01nF | ±(2.5%+3-dig) | |
| 600.0μF / 6.000mF / 60.00mF | 0.1μF | ±(3%+5-dig) | ||
| Frequency |
9.999Hz / 99.99Hz / 999.9Hz / 9.999kHz / 99.99kHz / 99.9kHz / 9.999MHz |
0.001Hz | ±(0.8%+2-dig) | |
| Duty Ratio | 0.1% - 99.9% (typical value: Vrms=1V, f=1kHz) | 0.10% | ±(1.2%+3-dig) | |
| 0.1% - 9 9.9% (≥1kHz) | ±(2.5%+3-dig) | |||
| Temperature | (-50℃) - (+400℃) | 1℃ | ±(2.5%+3-dig) | |
| (-58°F) - (+752°F) | 1℉ | ±(4.5%+5-dig) | ||
| Display | 5999 | |||
| Frequency | (40 - 1000) Hz | |||
| Shift Rate | 3 times/s |
