Limit Switch SPDT Micro Switch 1A 125V
Limit Switch SPDT Micro Switch 1A 125V
Regular price
Rs. 12.00
Regular price
Sale price
Rs. 12.00
Taxes included.
Flat Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
🎟️ Available Coupons — Copy & Apply at Checkout
100% Secure Payments
Verified & Protected
Accepted Payments
UPI
Mastercard
VISA
SSL Encrypted
256-bit Encryption
- Max. Switching voltage: 125 V
- Max. switching current: 1 A
- Max. switching frequency per minute: 60
- Contacts: NO, NC, COM
- Contact resistance: 100 mΩ
- Product Name：Micro Limit Switch. the micro switch is a very sensitive small switch, Activation requires only a small amount of force. Actuator Action: Momentary, Actuator Type: Hinge Lever
- Environmental Condition of utilization: Temperature -25~65℃；Relative humidity: below 85%; Rate Voltage: 125V AC; Rated Current: 1A
- Use: When in use, the conditions of the operating force are met, and the switch function is closed and turned on by applying pressure to the operating direction of the switch, and the switch is turned off when the pressure is removed. Its internal structure is connected and disconnected by the force change of metal shrapnel
- Application: Widely used in electronic equipment, communication equipment, military products, testing equipment, gas water heaters, small household appliances, floating ball equipment, medical equipment, power tools and general electrical and radio equipment, 24-hour timers, etc
The Microswitch KW10-Z1P Limit Switch 1A 125V AC contains one group of contacts for switching. Presence of the lever. Often used as a limit switch (end) in household appliances and amateur radio structures.
