LM2587 DC DC Boost Converter 5A 3-30V Step Up to 4-35V Power Supply Module
LM2587 DC DC Boost Converter 5A 3-30V Step Up to 4-35V Power Supply Module
Couldn't load pickup availability
Description:-
Module properties: non-isolated step-up module(Boost)
. Rectification: Non-Synchronous Rectification
. Input voltage: DC 3-30
--
1. Module properties: non-isolated step-up module(Boost)2. Rectification: Non-Synchronous Rectification3. Input voltage: DC 3-30V (Note: The boost module input voltage can not be higher than the output voltage,the output stable at the set value)4. Output voltage: DC 4-35V5. Output current: 5A MAX, (15mA unload)6. Conversion efficiency: 92% (MAX)7. Switching frequency: 100KHz8. Output ripple: 50mV (MAX)9. Load regulation: ? 0.5%10. Voltage regulation: ? 0.5%11. Operating temperature: -40 ?C to +85 ?C12. Potentiometer adjustment direction: clockwise (increase), counterclockwise (decrease)Package included:1 x LM2587 Module
