120mm 12V DC Cooling Fan (120x120x25)mm
Subcribe to back in stock notification
All Prices Incuding GST
Local Pickup
Estimated time to pack : 15 Mins.
Fast Delivery
Same Day Dispatch.
Bulk Purchase
• Input Voltage: 12VDC
• Current: 0.30A
• Noise: 36.5dBA
• Weight: 145g
• Wire Gauge: 26AWG
• RPM: 2200RPM @ 12VDC
• Air Flow: 80.6 CFM
• Dimensions: 120 x 120 x 25mm
• Wire Length: 40cm
• Ball Bearing mounted
--
This Brushless DC Cooling fans are operating at 12V with a dimension of 120x120mm. They are typically found in ATX Computer cases, but they can also be used in a variety of other projects requiring moderate airflow. The fan spins at ~2200 RPM and can move approximately 80CFM. It is fairly quiet – just 36.5dBA. There are two connectors commonly found in PCs on the end – a 4 pin Molex connector designed to fit inline with older style hard drive connectors and a smaller 3 pin Molex KK 2.54mm that is compatible with our 3pin Molex Header. To use the fan, simply connect Red to 12V, Black to Ground. The White wire is a Tach signal – it can be used to monitor the fan rotation or left disconnected if it isn’t needed.
