Features:

For the convenience of customers! The input voltage of this module is 3.3V / 5V , which is more convenient for development and use!

• VL6180X proximity, gesture and ambient light sensing (ALS) module.
• Slider switch controlling 2 functions:
• Ranging measurement, beyond 400mm.
• Ambient light sensing, up to 100 kLux1.
• 4-digit display, displaying either the distance of a target from the proximity sensor, or the lux value from the ambient light sensing (ALS).
• Excellent ranging accuracy, independent of the reflectance of the target.
• Basic gesture recognition application can be developed with one or multiple VL6180X modules.
• Compatible with STM32 Nucleo board family.
• Equipped with ArduinoTMUNO R3 connector.
• RoHS compliant.

After many experiments, we have a complete routine!If you need complete information, please buy the product to contact me!I will send it to you.

Wiring description:

1. The digital output of GPIO0 is 10 pins;

2.SDA pin of SDA connector development board;

3.SCL pin of SCL joint development board;

4. Power supply can be connected to 3.3V or 5V.

Instructions for module use:

1. Download the provided routine code to the WAVGAT development board;

2. Connect the VL6180 module with the development board according to the wiring instructions;

3. Open the serial port monitoring window of Arduino IDE;

4. When the sensor is not covered in front, the serial port monitoring window displays 255;

5. When there is occlusion, the distance is shown as measured distance and the unit is mm.

Package Includes:

• 1 x VL6180 VL6180X Range Finder Optical Ranging Sensor I2C Interface 3.3V 5V gesture recognition

Note: Product Images are shown for illustrative purposes only and may differ from the actual product
