Symbol VI IO Ptot Tstg Top DC Input Voltage Output Current Power Dissipation Storage Temperature Range Operating Junction Temperature Range Parameter² for to 18V for 20, 24V Value -35 -40 Internally Limited Internally Limited 150 °C Unit V

The L7905 series of three-terminal negative regulators is available TO-220FP, TO-3 and D2PAK packages and several fixed output voltages, making it useful in a wide range of applications. These regulators can provide local on-card regulation, eliminating the distribution problems associated with single point regulation; furthermore, having the same voltage option as the L7800 positive standard series, they are particularly suited for split power supplies. In addition, the -5.2V is also available for ECL system. If adequate heat sinking is provided, they can deliver over 1.5A output current. Although designed primarily as fixed voltage regulators, these devices can be used with external components to obtain adjustable voltages and currents. Symbol VI IO Ptot Tstg Top DC Input Voltage Output Current Power Dissipation Storage Temperature Range Operating Junction Temperature Range Parameter² for to 18V for 20, 24V Value -35 -40 Internally Limited Internally Limited 150 °C Unit V Absolute Maximum Ratings are those values beyond which damage to the device may occur. Functional operation under these condition is not implied. Symbol Rthj-case Rthj-amb Parameter Thermal Resistance Junction-case Thermal Resistance Junction-ambient Max 4 35 Unit °C/W
