1/4 inch Brass Water Flow Sensor SEN-HZ41WC
1/4 inch Brass Water Flow Sensor SEN-HZ41WC
Regular price
Rs. 449.00
Regular price
Sale price
Rs. 449.00
Taxes included.
Flat Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
- Material: Brass
- Color: Golden
- Flow Range: 0.35-3L/min
- Specification: 62*15*17mm
1/4 ” Brass Water Flow Sensor-SEN-HZ41WC, The pulse signal water flow sensor is widely applied in industrial equipment, agricultural equipment, and household electrical appliances in the future.
The water flow sensor consists of a plastic valve body, a water rotor, and a hall-effect sensor. When water flows through the rotor, the rotor rolls. Its speed changes with different rate of flow. The hall-effect sensor outputs the corresponding pulse signal.
Sensor Wire Details:
- 3-pin JST connector
- Red: Vcc
- Black: Ground
- Yellow: Pulse Output signal
Features/Specs
- Material: Brass
- Color: Golden
- Flow Range: 0.35-3L/min
- Specification: 62*15*17mm
- Used medium: Water
- Maximum Pressure: 1.2Mpa
- Working voltage: DC4.5-18V
- Custom Made: Wire harness specification
- Insulated Resistor: ≥100Ω
- Max Working Current: 15mA
Package Includes:
- 1 x 0.6 cm (1/4″) Brass Water Flow Sensor-SEN-HZ41WC
Note: Product Images are shown for illustrative purposes only and may differ from actual product.
