Technical Specifications:

• Input: 230v AC
• Wattage: 100 W
• Temperature: 550°c Max

• Bit Tip Type: Spade (BN100S8)
• Tip Size: 8mm
• Wire: 3 Core / 1/4 Meter Length
• Diamensions:   Gun Length (15Handle+12Heating Arm)= 27 CM
                           Body Diameter: 3.3 cm max
                           Bit Tip Diameter: 8.6 mm

Ideal for the electrical and automotive industries. Comes with comfortable rubber coated handle. Continuous rated (24 hours)

Our heaviest of duty irons is intended for going where no smaller iron will do. Used in applications such as:

• Tinning up to 10sqmm(approx) wire lugs

• Soldering up to 10sqmm(approx) lugs

• Soldering copper sheets up to 1mm thick (approx)

• Large component soldering such as

  • Silicon Controlled Rectifier(SCR)

  • TRIACs

  • Diodes

  • Etc

• Various large terminal soldering

• Heavy electrical work

• Motor winding

Imp. Note: Only copper, brass and solderable metals will adhere to the solder. Stainless Steel, Aluminium will not adhere.
