NE 555 Pulse Frequency Duty Cycle Adjustable Module Square Wave Signal Generator
NE 555 Pulse Frequency Duty Cycle Adjustable Module Square Wave Signal Generator
Regular price
Rs. 89.00
Regular price
Sale price
Rs. 89.00
Taxes included.
Flat Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
- Main chip: NE555
- Input Voltage: 5V-15V DC.
- Generate an adjustable pulse for MCU.
- Generate an adjustable pulse, to control circuitry associated.
NE555 Pulse Frequency Duty Cycle Adjustable Module Square Wave Signal Generator is a 5 V square wave signal generator. It generates a square wave signal used for experimental development. Also, use to drive a stepper motor for generating a square wave drive signal.
The output duty cycle can fine-tune. The duty cycle and frequency is not separately adjustable, adjusting the duty cycle will change the frequency.
The output frequency is adjustable:
Period T = 0.7 (RA +2 RB) C
RA, RB is 0-10K adjustable;
Low profile when C = 0.001UF;
IF stalls C = 0.1UF;
High-frequency file C = 1UF;
HF stalls C = 100UF;
So buyers can calculate the frequency of the waveform.
