SG3525 PWM Controller IC (Pulse Width Modulator)

• 8 TO 35 V OPERATION

• 5.1 V REFERENCE TRIMMED TO ± 1 %

• 100 Hz TO 500 KHz OSCILLATOR RANGE

• SEPARATE OSCILLATOR SYNC TERMINAL

• ADJUSTABLE DEADTIME CONTROL

• INTERNAL SOFT-START

• PULSE-BY-PULSE SHUTDOWN

• INPUT UNDERVOLTAGE LOCKOUT WITH HYSTERESIS

• LATCHING PWM TO PREVENT MULTIPLE PULSES

• DUAL SOURCE/SINK OUTPUT DRIVERS

3525A is a monolithic integrated circuit that Included all of the control circuit necessary for a pulse width modulating regulator.There are a voltage reference, an error amplifier, a pulse width modulator, an oscillator, under-voltage lockout, soft start circuit, and output drivers in the chip.
